Preheaters

CONTACT INDUCTIVE PREHEATERS
NON-CONTACT INDUCTIVE PREHEATERS


Full range of inductive style units capable up to 200°C preheating temperature, designed for bare wire or braided core to improve polymer adhesion and added cleaning.  Line speeds from 50 to 2000 mpm, variety of pulley diameters, manual or automatic mode, custom configuration based on line speed and temperature specifications, line speed follower.  Multiple zone gas flame preheaters and hot air tube systems also available.

We offer the following components with short delivery times and exceptional competitive pricing:

Custom designed induction preheaters to meet you specifications.
High frequency (4000Hz) induction pre-heater: Middle  frequency (250Hz) induction pre-heater: Low frequency (50Hz) induction pre-heater:
Conductor diameter: 0.3 mm to 1.0 mm Conductor diameter: 0.3 mm to 3.0 mm Conductor diameter: 0.5 mm to 3.0 mm
Preheating temperature: 120° C to 200° C
Preheating temperature: 120° C to 200° C Preheating temperature: up to 120° C
Line speed:  600 m/m to 2000 m/m Line speed:  300 m/m to 600 m/m Line speed:  50 m/m to 300 m/m
Guide pulley diameter: 180 mm Guide pulley diameter:  250 mm Guide pulley diameter:  380 mm
   All pre-heaters feature:
  • Low resistance as the wire passes through the pre-heater so it will not be stretched.
  • Guide pulley's that are surface sprayed with ceramic, which ensures a long service life.
  • Automatic power output changes with the variation of the line speed, ensuring the preheating temperature remains the same at different line speeds.
